B00015 – 1873 TAB VG Series

Product Type: B0000 Plastic Slatband Chain

B00015 – 1873 TAB VG Series

The B00015 – 1873 TAB VG Series is engineered for applications requiring high friction and secure handling, such as bottling. The rubber top design supports stable product transport, while the side-flexing capabilities allow for smooth navigation of curves. Constructed with materials like LF Brown and heat-resistant rubber, this series provides durability and high load capacity. The flexible chain base can twist 90° in 1500 mm, enabling compact layouts and extended conveyor lengths.

Material/s

Available in LF Brown and Austenitic with rubber options.

Solution/s

Colour/s

Varies by material type

Product information:

Key Features & Benefits

LF Brown: Low-friction material, ideal for smooth operation and minimal wear. Austenitic: Corrosion-resistant, suitable for environments with exposure to moisture. Rubber (85 Shore A): Heat-resistant rubber top, providing high friction for secure handling.

High-speed performance with very high load capacity.
High-friction rubber top ensures secure product handling and stability.
Designed for gentle handling in bottling applications to prevent product distortion.
Side-flexing design enables smooth transitions in curved conveyor paths.
Rubber top is heat-resistant, allowing for use in high-temperature environments.
Chain flexibility allows for compact and extended conveyor layouts.

Solution Features & Benefits

Breaking Load: 21000 N (4730 lbs) to 21600 N (4760 lbs) depending on configuration. Width (WR): Varies by configuration (e.g., 185.5 mm, 295 mm) Minimum Radius (R): 750 mm Weight: 3.4 kg/m to 4.9 kg/m depending on configuration

Standard Order Quantity: Standard Length: 80 pitches (10 ft / 3.048 meters / 80 flights)

Industries & Ideal Applications

Bottling: Ideal for bottling lines where gentle handling and secure positioning are critical, preventing bottle distortion.
Food & Beverage: Suitable for food and beverage processing lines with high-speed and high-load requirements.
Designed for gentle handling in bottling applications to prevent product distortion.
Side-flexing design enables smooth transitions in curved conveyor paths.
Logistics & Warehousing: Suitable for warehouses and distribution centers with high-speed, heavy-load conveyor systems.
