2120M Series-Side Flex–Flat Top MagneticFlex (FTM)
Catalogue code: E00002-A1
2120M Series
SIDE FLEXING
FLAT TOP MAGNETIC-FLEX (FTM)-K330
The 2120M Flat Top Magnetic-Flex belt is engineered for high-performance side-flexing applications, using a mold-to-width design (K330) for optimal strength and flexibility. Made from NGE DRY (advanced performance polymer alloy), this belt uses magnetic stainless steel pins for smooth operation and easy assembly. Ideal for conveying in dry, high-speed environments, it combines strength, flexibility, and low maintenance.
Colour/s
NGE Dry Grey Blue
Material/s
Belt: NGE DRY Grey Blue (Advanced performance polymer alloy) Pins: Magnetic Stainless Steel
NGE DRY is a high-grade engineering plastic with enhanced wear resistance and strength, optimized for dry applications. The magnetic stainless steel pins improve durability and enable secure, easy linkage.
Advanced NGE DRY material for dry high-speed applications.
Side-flex design with tight radius capabilities (500mm min).
Magnetic stainless steel pin assembly for reliable connection.
Mold-to-width design ensures smooth belt tracking and minimal gap.
Lightweight (1.18 kg/m), reducing energy consumption.
High working load capacity (1000 N/M or 450 lbs/ft).
Solution Features & Benefits
Allows flexible routing with tight turns.
Resistant to wear and deformation under load.
Magnetic pins simplify maintenance.
Industries & Ideal Applications
Beverage Bottling: Side flex movement around fillers and packers.
Food Processing (Dry): For applications not requiring washdowns.
Magnetic stainless steel pin assembly for reliable connection.
Mold-to-width design ensures smooth belt tracking and minimal gap.
Electronics Assembly: Low-dust, high-precision belt movement.
