E00008B-A6-2540-1005 Straight Running Series-Flat Top – Low Back Pressure (LBP)

E00008B-A6-2540-1005 STRAIGHT RUNNING SERIES-FLAT TOP – LOW BACK PRESSURE (LBP)

E00008B-A6-2540-1005 STRAIGHT RUNNING SERIES-FLAT TOP – LOW BACK PRESSURE (LBP) (4)

E00008B-A6-2540-1005 STRAIGHT RUNNING SERIES-FLAT TOP – LOW BACK PRESSURE (LBP) (3)

Product Type: E0000 Modular Belts

E00008B-A6-2540-1005 Straight Running Series-Flat Top – Low Back Pressure (LBP)

The Low Back Pressure (LBP) Straight Running Series is engineered to provide efficient and controlled product flow in high-speed conveyor systems. Utilizing Low Friction Acetal Grey (LFAG) with PBT pins, this belt is specifically designed to minimize back pressure, making it ideal for applications where smooth and uninterrupted product movement is crucial. The LBP design integrates rollers into the belt to reduce friction between the conveyed items and the belt surface, ensuring that products flow seamlessly through the system without jamming or accumulating excessive pressure. This belt is perfect for industries that require high throughput and gentle product handling.

Material/s

Low Friction Acetal Grey with PBT Pins

Solution/s

XLG, Low Back Pressure – LBP

Colour/s

Grey (LFAG)

Product information:

Key Features & Benefits

LFAG: Low Friction Acetal Grey is a high-performance material optimized to reduce friction, ensuring smooth product flow and minimizing wear on both the belt and the products being conveyed.

Low Back Pressure: Designed to minimize back pressure on products, reducing the risk of jams and damage.
High Throughput: Ideal for high-speed operations requiring smooth and efficient product flow.
Low Friction (LFAG): The LFAG material reduces friction, minimizing wear on system components and products.
Gentle Product Handling: The integrated rollers ensure gentle handling of products, preserving product integrity during transportation.
Versatile Applications: Suitable for a wide range of industrial uses, particularly in high-speed conveyor systems where product flow control is essential.
Easy Maintenance: The belt's design reduces maintenance requirements, lowering operational costs.

Solution Features & Benefits

Standard Order Quantity: Per Meter

Industries & Ideal Applications

Food & Beverage: Ideal for high-speed bottling lines where smooth and controlled product flow is critical.
Packaging: Suitable for packaging lines that require gentle handling and minimal product pressure during conveyance.
Low Friction (LFAG): The LFAG material reduces friction, minimizing wear on system components and products.
Gentle Product Handling: The integrated rollers ensure gentle handling of products, preserving product integrity during transportation.
Logistics & Distribution: Ensures efficient product movement in high-speed sorting and distribution systems.
