Product Type: E0000 Modular Belts

E00010-B-D-3175 Straight Running Series-Flush Grid With Flights/Cleats (D)-ATW = (Assembled To Width)

The 3175 STRAIGHT RUNNING SERIES with Flush Grid and Flights/Cleats is engineered for applications that demand both efficient drainage and controlled product movement. The open flush grid design ensures quick drying and efficient drainage, while the integrated flights/cleats provide additional grip and stability for products being conveyed on inclines or declines. Available in various materials, including LFAG (low-friction Acetal), PPW (Polypropylene), PPB (Dark Blue Polypropylene), and NPE (Polyethylene), this belt offers excellent performance in a range of environments, both wet and dry. The belt is customizable with various pitch, indent, and flight height options, making it adaptable to specific industrial needs.

Material/s

LFAG (Grey): Low Friction Acetal with PBT pins PPW (White) & PPB (Dark Blue): Polypropylene with PBT pins NPE (Natural): Polyethylene with Polyethylene pins

Solution/s

Flush Grid , Metal-free Polymer – LFADB, Flights/Cleats, Chemical-Resistant – PPB-PPW, Cold/Freezing Temperatures – NPE

Colour/s

LFAG (Grey) PPW (White) PPB (Dark Blue) NPE (Natural)

Product information:

Key Features & Benefits

LFAG (Grey): Provides low friction, reducing energy consumption and wear, ideal for dry environments. PPW (White) & PPB (Dark Blue): Chemically resistant, making them ideal for environments exposed to cleaning agents. NPE (Natural): Flexible and resilient, suitable for low-temperature applications, ensuring durability in extreme conditions.

Efficient Drainage: The flush grid design allows liquids to pass through easily, making it ideal for wet processes.
Enhanced Grip: Integrated flights/cleats provide additional grip, ensuring stable product handling on inclines and declines.
Customizable Options: Available in various pitches, indents, and flight heights to meet specific application requirements.
High Load Capacity: Supports up to 20,000 N/m, depending on the material and configuration.
Temperature Resilience: Performs efficiently in temperatures ranging from -70°C to 82°C.
Versatile Application: Designed for use in both dry and wet environments, offering reliable performance across various industries.

Solution Features & Benefits

Flush Grid Applications: Allows for better air circulation and drainage, making it suitable for applications where hygiene and cleanliness are crucial.
Metal-free Polymer Applications: Ideal for industries requiring non-metallic components to avoid contamination, corrosion, or interference with sensitive machinery and products.
Flights/Cleats Applications: Enhances the conveyance of bulk materials on inclines by preventing backsliding and improving feed rates.

Standard Order Quantity: Per meter

Industries & Ideal Applications

Food Processing: Ensures stable and controlled movement of food products on inclined surfaces, reducing the risk of slippage, with efficient drainage.
Packaging: Ideal for packaging lines that require secure handling of products, particularly in processes involving elevation changes and wet environments.
Customizable Options: Available in various pitches, indents, and flight heights to meet specific application requirements.
High Load Capacity: Supports up to 20,000 N/m, depending on the material and configuration.
Pharmaceutical Industry: Maintains product integrity during transport, offering enhanced control in sterile environments with efficient drying capabilities.
